Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 350W
Optics
▪ Light source: 1*150W White+1*150W Warm white
▪ Color temp : 1800K-6500K
▪ Drive Mode: Constant Current
▪ CRI: >90RA
Color System
▪ Color: Warm White+Cool White
Effects
▪ Lens angle: 60°
▪ Moving angle: ±25° (each lamp is controlled by an individual motor)
▪ Dimming: 0-100% linear
▪ Strobe: 0-25 times/second
▪ Splicable body connection
▪ Hang on truss: suggest maximum 4PCS
▪ Noise(5m):<50DB
Control and Programming
▪ Control Mode: DMX512/RDM
▪ Control Channels: 8/12
▪ Display: LED
Connections
▪ Data in/out:3-pin
▪ Power in/out: fixed cable
Thermal Management
▪ Over temperature protection
▪ Cooling fans intelligent speed regulation
▪ Thermal management system ensures long life of LEDs
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C (104° F)
▪ Minimum ambient temperature (Ta min.): 5° C (41° F)
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: die-cast aluminum + alloy
▪ Color: Black
▪ Housing surface treatment: baking finished treatment
▪ Protection rating: IP65
Mechanical Specification
▪ Length: 650 mm
▪ Width: 140 mm
▪ Height: 394 mm
Weight
▪ Net Weight: 9.9kg
