Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 300W
Optics
▪ 10X30W RGBW (4IN1)
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
Color System
▪ Color Mixing: RGBW (4IN1)
Effects
▪ Strobe: 0-30Hz
▪ Dimming : 0% – 100% (16-bits dimming)
▪ Variable Dimming Curves
Control and Programming
▪ Protocal: DMX 512
▪ Control Modes: DMX, Master/Slave, Sound Active
▪ DMX channels: 1/8/44CH
▪ Setting and addressing: Control panel with backlit graphic display
▪ Built-in programs
▪ Display: LED
Connections
▪ Data in/out:3-pin (5-pin XLR optional)
▪ Power in/out: PowerCon
Cooling System
▪ Cooling: Natural heat dissipation
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: Aluminum diecast+Plastic
▪ Color: Matte Black
▪ Protection rating: IP20
Mechanical Specification
▪ Length: 1000 mm
▪ Width: 82 mm
▪ Height: 183 mm
Weight
▪ Weight: 6.0kg
Accessories
▪ Power input cable included, length 1mtr
▪ DMX cable included, length 1mtr
▪ Safety cable not included (optional)
Approvals
▪ CE
