Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 100W
Optics
▪ Beam angle: 30° (60° optional)
▪ Reflector material: aluminum
▪ Parabolic reflector with high luminous efficiency
▪ 16 bit smooth dimming
Color System
▪ RGBWA+UV 6IN1, 3000k-6500k
Effects
▪ Strobe: 1-25Hz
▪ Dimming : 0% – 100%
▪ Built-in strobe macro and speed adjustable
▪ Flicker free (refresh rate >4K Hz)
Control and Programming
” ▪ Control mode:
DMX, Master/Slave, Autorun”
▪ DMX Channels: 3/4/6/7/8/13CH
▪ Onboard programming functionality enables programming without external DMX controller
▪ Setting and addressing: 4-digit LED
Connections
▪ Data in/out: XLR 3Pin (XLR 5Pin is optional)
Cooling System
▪ Heatsinks in aluminum
▪ Cooling: natural convection (no fan, no noise)
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): 5° C
Safety Devices
▪ Electronic protection against short circuit
▪ With one eye bolt at the rear
Construction
▪ Housing: die-cast aluminium head + aluminum alloy body
▪ Color: Black
▪ Housing surface treatment: baking finished
▪ Protection rating: IP20
Mechanical Specification
▪ Length: 260 mm
▪ Width: 190 mm
▪ Height: 300 mm
Weight
▪ Net Weight: 5.50 kg
Accessories
▪ Power input cable: 1.0mm2, PVC sheath, length 1.4mtr
▪ Power cable sheath material: PVC
▪ DMX cable excluded (optional)
▪ Safety cable excluded (optional)
▪ Barndoor excluded (optional)
