POWER SUPPLY
▪ Power supply: AC100V-240V; 50/60Hz
▪ Power consumption: Max. 300W
▪ Power In/Out: Powercon, daisy chain
LIGHT SOURCE
▪ LED：36pcs 10W, RGBW 4-in-1, brand CREE
▪ Color temp: 9500-9800K
▪ CRI: Ra>78
▪ Luminous flux: Max. 12,000 lm
▪ Drive mode: constant current
▪ Drive current: 750mA
OPTICS
▪ Beam angle: 90°x120°
▪ Light ouput (full right): 1,106Lux@3mtr; 479Lux@5mtr
▪ Optic lens: acrylic
▪ Reflector:
High temperature resistant plastic
Parabolic reflector with high luminous efficiency
Unique reflector ensure colors more pure
DIMMER & STROBE
▪ Electronic dimming: 0-100% linear, 16bit smooth dimming
▪ Refresh rate: >4K Hz (Flicker free) , suitable for TV applications and all video recorded events
▪ Electronic strobe: 1-25 flashes/sec.
EFFECTS
▪ Built-in color macro: color fade in & out, color jumping
▪ Built-in demo: Built-in 5 demo programmes, speed adjustable
▪ Dot matrix: in 2 sections, individual colors control of each
CONTROL MODE
▪ Control protocol: DMX512
▪ Control mode: DMX, Master/Slave, Autorun
▪ DMX channels: 4/10CH
▪ DMX data In/Out: XLR 3Pin (XLR 5Pin optional)
DISPLAY & MENU SETTING
▪ Display: 2.6inch blue LCD backlit
▪ Setting and addressing: via 4-menu-button
▪ Menu language: English
PAN-TILT
▪ Tilt: 0º～120º (head)
BODY & HOUSING
▪ Housing: aluminium+iron
▪ Housing surface: baking finished treatment
▪ Housing color: black (white optional)
COOLING
▪ Heatsinks: in aluminum
▪ Cooling for head: natural convection
▪ Cooling for base: forced air convection
THERMAL MANAGEMENT
▪ Thermal management
Over temperature protection
Auto reduce light output in case of overheating
Thermal management system ensures long life of LEDs
SAFETY PROTECTION
▪ Fuse: 5A 120V, 3.15A 240V
▪ Electrical protection: Electronic protection against short circuit
▪ Rigging protection: with safety chain through holes at the mounting bracket
RIGGING & MOUNTING
▪ Rigging: 2pcs omega brackets with 1/4-turn quick fasteners
▪ Mounting:
With mounting bracket
Double handles (left & right) for carry and easy handling
Four strong feet for better and stable flat placement
ENVIRONMENT AND PHYSICAL
▪ IP rating: IP20
▪ Environment temperature: -20°C-40°C
▪ Dimensions(mm): W602 x D214 x H235
▪ Net weight: 9.5kg
ACCESSORIES
▪ Power input cable: 1.5mm2, PVC sheath, length 1.4mtr
▪ DMX cable: included, length 1.5mtr
▪ Hanging omega bracket: not included (optional)
▪ Safety cable: not included (optional)
