LM-360A2(4IN1)B

LED Mantis, 3X60W Warm White, 36X3W RGB 3IN1, IP20, Black Shell

Categories: .

Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 250W

Optics
▪ Optics: High reflective hammered reflector
▪ LED:3 x LED dim to warm white, 3 x RGBW Glow, 1 x RGBW Center box
▪ Color rendering index(CRI): Ra>90
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current

Color System
▪ Color Mixing: RGBW (4IN1)
▪ Color Temperature: 1600-3200K

Effects
▪ Strobe: 1-25Hz
▪ Dimming : 0% – 100%

Control and Programming
▪ DMX Channel Mode:15/20/26 CH
▪ Control Mode:DMX512, RDM, W-DMX
▪ Built-in programs: effects with color, dimming, strobe and chases

Connections
▪ Data in/out: 2 XLR5 In/Out ,2 XLR3 In/Out, 1 powerCON TRUE1 In

Work Enviroment
▪ Maximum ambient temperature (Ta max.): 60° C
▪ Minimum ambient temperature (Ta min.): -40°  C

Construction
▪ Housing: Metal Construction
▪ Color: Black
▪ Protection rating: IP20

Mechanical Specification
▪ Length: 650 mm
▪ Width: 650 mm
▪ Height: 170 mm

Weight
▪ Weight: 8.0kg

Accessories
▪ Power cable included, length 1mtr
▪ DMX cable included, length 1mtr
