Source
•Leds: 4X30W 4IN1+60pcs SMD 5050 3IN1
•LED Life Expectancy: Minimum 50.000 hours
•Drive Mode: Constant Current
Optics
•Beam Angle: 7.2°
•Color temperature: 8000K
•CRI (Ra>): 85
•Dimmer: 0-100%
•Strobe: 1-25Hz
•Lux @ 3 Meter: 9800Lux
Lux @ 5 Meter: 3200Lux
Control and programming
•Control Mode: DMX, autorun, Master/Slave, Sound-activate
•Control Channels: 17/38CH
•Display: LED
Power Supply:
•Power supply: Electronic auto-ranging
•Power Input Rating: 100-240 V AC, 50-60 Hz
•Power consumption: 170W
•Power Connectors In/Out Powercon
Data Connection:
•Data Connectors In/Out: XLR 3Pin (XLR 5Pin is optional)
Body
• Housing: die-cast flame retardant plastic
• Housing color: black (white optional)
• Housing surface treatment: baking finished
Safety Devices
• Power failure memory
• Electronic protection against short circuit
Work Enviroment
•Enviroment temperature: -25 °C -40 °C
Cooling System
“• Cooling fan speed auto change according to temperature
“• Cooling fans auto start once internal temperature reach 45º
Internal protection
• IP rating: IP20
Mechanical Specification
•Length: 258 mm
•Width: 168 mm
•Height: 369 mm
•Weight: 6.0 kg
Approval:
•CE
Accessories
• Power cable included
• Power cable: 0.75mm2, PVC
• DMX cable included
• Safety cable not included (optional)
