OPTICAL
• Light Source: 5x120W RGBL LEDs，120×0.5W RGB LEDs
• Color Temperature (range): 2700 to 8000 K
• Beam angle：3-0°
DYNAMIC EFFECTS
• Pan：60°，Tilt:220°
• Dimmer: 0-100% 16bit dimming
• Shutter/Strobe: Electronic
• Strobe effect：0-20HZ strobe、Puls strobe、Random strobe
• Color Temperature Presets: Yes
• Dim Modes: 4
COLOR
• Uniform RGBL mixing color
• LED pixel control of the outer ring to create a more gorgeous chasing effect
DISPLAY
• 2.4-inch TFT display screen which Can be exchanged in Chinese and English
• 4 touch buttons
• The key lock can be set to prevent incorrect operation
• The display screen can reversed by 180°，which is suitable for installation in different positions
SOFTWARE
• Software Upgrade：Upgrade with DMX signal cable
• It Shows the usage time of the fixture to make customers convenient to understand the use of the fixture in a timely manner
CONTROL
• 2 DMX channel modes：41/71CH
• 2 control modes:DMX512、Maser-Slave
• SettingandAddressing：RDM
COOLING SYSTEM
• LED temperature detection system to protect the service life of LED chip
• Cooling : silent fan
POWER SUPPLY
• Power supply: Electronic auto-ranging
• Power Input Rating: 100-240 V AC, 50-60 Hz
• Power consumption: 680W
• Power Connectors In/Out Powercon
DATA CONNECTION
• Data Connectors In/Out: XLR 3Pin (XLR 5Pin is optional)
INTERNAL PROTACTION
• IP rating: IP20
CONSTRUCTION / PHYSICAL
• Dimensions: 1002x196x334mm
• Weight: 29.0 kg
• Exterior Color: Black
• Housing Material: metal+ABS plastic
ACCESSORIES
• Power cable included
• DMX cable included
• Safety cable not included (optional)
• Hanging bracket not included (optional)
• Flightcase not included (optional)
