Electrical
▪ Input voltage: 100-240 V AC, 50-60 Hz
▪ Max. power consumption: 200 W
▪ Lumen Output: 2500 Im
▪ Intensity: 375,000 cd in narrow beam
Optics
▪ Light source: 120W RGBL+48X1W RGBWW
▪ Led Life Expectancy: minimum 50.000 hours
▪ Beam Angle: 3.8°-38°
▪ 140 mm Fresnel lens
Photometric Data
▪ Strobe: 1-20/second
Color
▪ Beam color mixing: RGBL 4IN1
Effects
▪ Defined narrow beam
▪ Soft edge wide wash
▪ Minimal stray light
▪ Minimal color temperature
▪ shift from center to edge
Color Palette
▪ RGBL color mixing with very bright and vibrant saturated colors, as well as soft pastels and white tones
▪ Calibrated and Extended Color Modes
▪ Calibrated Color
▪ Temperature Control: 2,000-12,850 K
▪ Calibrated Green Magenta Shift ( Tint)
▪ Tungsten Emulation Option
▪ Virtual Color Wheel
Control and Programming
▪ DMX,M/S( Art-Net, sACN optional)
▪ 20/38/221 DMX Channel Modes
Connections
▪ Data in/out: 3-pin or 5-pin waterproof XLR
▪ Power in/out: Waterproof power connector in/out
Thermal
▪ Cooling: waterproof fan
▪ Maximum ambient temperature (Ta max.): 40° C (104° F)
▪ Minimum ambient temperature (Ta min.): 5° C (41° F)
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Color: Black
▪ Housing: module pressing high strength alloy
▪ Protection rating: IP65
Weight and dimensions
▪ Net Weight: 7.0 kg
▪ Dimensions (WxHxD): 282x250x364.8 mm
Accessories
▪ Power input cable included, length 1.0mtr
▪ DMX cable included, length 1.0mtr
