LMHBSZ-250A1(3IN1)B

LIGHT SOURCE
● Light Source: 250W High Output White LED
● Output Lamp power: 250W
● Color temperature: 8,000K
● Color rendering index(CRI): Ra>75
● High light output,10500LUX@5M at White light zoom in
800LUX@5M at White light zoom out
● Average life: 5,000hrs
OPTICS
● Lens at the front of head: Dichroic Glass
● Lenses: Multi-set high precision optical Lens
● Zoom angle 5.5°~30°, focus function
● Electronic linear focus
COLORS
● Color wheel: 7 colors +white, color fine tuning, rotation with variable direction and speed
GOBOS
● 1 Rotation Gobo Wheel: 7 gobos + white, wheel rotation and shake
● 1 Static Gobo Wheel: 8 gobos + white, wheel rotation and shake
● Gobo flow at variable speeds in bi-directions
EFFECTS
● Prism: 8-facet Prism, bi-directional rotatable at variable speeds
● Frost effect
● Strobe: High speed strobe effect with 1-25 flashers per second
● Dimmer: 0-100% mechanical dual shutter
● Built-in movement and effects macros
CONTROL AND PROGRAMMING
● Control mode: DMX, autorun, master/slave, sound activated
● DMX channels: 16/18CH
● Display: LCD backlit, with English/Chinese menu
● DMX data In/Out: 3-pin & 5-pin XLR connectors IN/OUT
● Reset: via DMX and/or operate panel
● Remote ON/OFF lamp, reset by DMX and/or panel
PAN-TILT
● Pan: Max 540°, with 8 or 16 bit resolution
● Tilt: Max 270°, with 8 or 16 bit resolution
● Automatic Pan/Tilt correction
● Pan/Tilt motors: 3 phase, fast and quiet movement
BODY
● High strength alloy inner stucture
● Housing: die-cast flame retardant plastic cover
● Housing Color: Black (White optional)
● Two side handles for transportation
● Pan and Tilt locking mechanisms
POWER SUPPLY
● Power consumption: 350W
● AC100-240V, 50/60Hz (auto-ranging)
● Auto switching power supply
● Ballast type: electronic
● Power In: blue powercon
SAFETY DEVICES
● with thermal protection
● Thermal sensor monitors the lamp ignition and ensures the
fixture works at proper temperature
● Cooling: forced air convection
RIGGING
● 2 Omega brackets with 1/4-turn quick locks
● 1 safety rope included
ENVIRONMENT AND PHYSICAL
● IP rating: IP20
● Environment temp: -20°C-40°C
● Dimensions(mm): 320(L)*220(W)*480(H)mm
● Net Weight: 13.5kg
