Source
• Leds: 1pc COB 150W cool white
• LED Life Expectancy: Minimum 50.000 hours
• Drive Mode: Constant Current
Optics
• Beam Angle: 4.5°-22 °
• Color temperature: 9000K
• CRI (Ra>): 77
• Dimmer: 0-100%
• Strobe: 0-20Hz
Gobo Wheel
• 1 Rotation Gobo Wheel: 5 glass gobos + 2 open, wheel rotation and shake
Color Wheel
• 1 Color Wheel: 7 colors+white, color fine tuning, rotation with variable direction and speed
Prism
• 8-facet Prism, bi-directional rotatable at variable speeds
Control and programming
• Control Mode: DMX, autorun, Master/Slave, Sound-activate
• Control Channels: 16/14CH
• Display: LCD
Power Supply:
• Power supply: Electronic auto-ranging
• Power Input Rating: 100-240 V AC, 50-60 Hz
• Power consumption: 190W
• Power Connectors In/Out Powercon
Data Connection:
• Data Connectors In/Out: XLR 3Pin (XLR 5Pin is optional)
• Wirelss DMX Data In: XLR 5Pin (XLR 3Pin optional)
Body
• Housing: die-cast flame retardant plastic
• Housing color: black (white optional)
• Housing surface treatment: baking finished
Safety Devices
• Power failure memory
• Electronic protection against short circuit
Work Enviroment
• Enviroment temperature: -25 °C -40 °C
Cooling System
• Thermal management system ensures long life of LEDs
• Automatic reduce brightness in case of overheating
• Heatsinks in aluminum
• Cooling for head: forced air convection with 1 fan
• Cooling for base: forced air convection with 1 fan
• Cooling fan speed auto change according to temperature
• Cooling fans auto start once internal temperature reach 45º
Internal protection
• IP rating: IP20
Mechanical Specification
• Length: 328 mm
• Widthe：220mm
• Height: 482 mm
• Weight: 13.0 kg
Approval:
• CE
Accessories
• Power input cable included, length 1.2mtr
• Power cable: 0.75mm2, PVC
• DMX cable not included (optional)
• Safety cable not included (optional)
• Hanging bracket included (2pcs/pair)
