ELECTRICAL
▪ Power supply: Electronic auto-ranging
▪ Color Temperature : 6500-6800K
▪ Beam Angle: 6.5°-50°
▪ Power consumption: 327W
OPTICS
▪ Light Source: 18x15W, RGBW 4-in-1
▪ Drive Mode: Constant Current
COLOR SYSTEM
▪ Color Mixing: RGBW
DYNAMIC EFFECTS
▪ Pan and Tilt: 540°/270°
▪ Dimmer: Electronic
▪ Shutter/Strobe: Electronic
▪ Zoom: Motorized
▪ Strobe Rate: 0 to 20 Hz
▪ Zoom: Motorized
▪ Focus: Electronic
▪ Strobe Rate: 0 to 20 Hz
▪ Color Temperature Presets: Yes
▪ Dim Curves: 4
CONSTRUCTION / PHYSICAL
▪ Dimensions: 330x230x290 mm
▪ Weight (single unit):10.0kgs
▪ Exterior Color: Black
▪ Housing Material: Plastic
▪ Display: LCD
CONNECTIONS
▪ Power In/Out: Powercon
▪ Cable Length (power): 1M
▪ Signal Connection: 3pin (5pin optional)
CONTROL
▪ Control Protocol: Auto, Sound Active, Slave Master, DMX
▪ DMX Channels: 20/40 CH
COOLING SYSTEM
▪ Cooling: forced air convection, with 1 slient fan,fans’ speeds adjustable
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
SAFETY DEVICES
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
CERTIFICATIONS / QUALIFICATIONS
▪ CE
▪ IP Rating: IP20 (indoor use)
WHAT’S INCLUDED
▪ LMHBZ-1518-A1(4IN1)B
▪ Power cable 1 pc
▪ Signal cable 1pc
▪ Omega bracket with mounting hardware
OPTIONAL ACCESSORIES
▪ Clamps
▪ Flightcase
