ELECTRICAL
▪ Power supply: Electronic auto-ranging
▪ Beam Angle: angle：4-40°（Wash） ；4-40°（Beam）；120°（Pixel）
▪ Power consumption: 600W
OPTICS
▪ Light Source: 4x60W RGBW LED,（Wash ）；9x10W CW LED,(Beam)；72×0.5W RGB LED, （Pixel ）；96x1W CW LED, （Pixel ）
▪ Optics lens：high brightness PMMA lens
▪ Life Span：50000H, low power consumption, energy saving and environmental protection
COLOR SYSTEM
▪ Color: Uniform RGBW mixing color system(（Wash）)
▪ Uniform RGB color mixing, andd ynamic pixel effect（Pixel）
▪ CW LEDs strong strobe and beam effect（Beam&Pixel）
MOVEMENT
▪ Pan/Tilt movement：: Pan : 540° ,Tiit : 540°
▪ Smooth and accurate positioning
▪ Adjustable Pan and tilt speed
▪ Pan and Tilt with error correction function
▪ The scanning position can be memorized and it will be reset automatically after no expected movement
▪ 16bit fine
DYNAMIC EFFECTS
▪ Strobe effect：0-20HZ strobe、Puls strobe、Random strobe
▪ Dimming：0-100% 16bit dimming
CONSTRUCTION / PHYSICAL
▪ Dimensions: 425X325X150mm
▪ Weight (single unit):12.4kg
▪ Exterior Color: Black
▪ Housing Material: ABS plastic fireproof material
▪ Display: 2.4-inch TFT display screen which Can be exchanged in Chinese and English
▪ 4 touch buttons
▪ The key lock can be set to prevent incorrect operation
▪ The display screen can reversed by 180°，which is suitable for installation in different positions
CONNECTIONS
▪ Power In/Out: Powercon
▪ Cable Length (power): 1M
▪ Signal Connection: 5-pin (3-pin optional)
CONTROL
▪ Control Protocol: DMX512、Maser-Slave
▪ DMX Channels: 24/39/97CH
▪ Setting and Addressing：RDM
COOLING SYSTEM
▪ Fan heat dissipation (the fan speed changes as per the temperature change)
▪ LED temperature detectio snystem to protect the service life of LED chip
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
SAFETY DEVICES
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
QUALIFICATIONS
▪ IP Rating: IP20 (indoor use)
WHAT’S INCLUDED
▪ Power cable 1 pc
▪ Signal cable 1pc
OPTIONAL ACCESSORIES
▪ Clamps
▪ Flightcase
