Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 220W
Optics
▪ 7X30W RGBW(4IN1), Tianxin Led
▪ Lens: High-efficiency 67 mm PMMA optics
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
Color System
▪ Color Mixing: RGBW (4IN1)
Effects
▪ Strobe: 0-30Hz
▪ Dimming : 0% – 100% (16-bits dimming)
▪ Variable Dimming Curves
Control and Programming
▪ Control Mode: DMX512, Auto, Master-Slave, Music
▪ Protocal: DMX 512
▪ DMX channels: 15/39 CH
▪ Setting and addressing: Control panel with backlit graphic display
▪ Built-in programs
▪ Display: LCD
Connections
▪ Data in/out:3-pin & 5-pin XLR
▪ Power in/out: PowerCon
Cooling System
▪ Cooling: Forced air
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: Plastic
▪ Color: Matte Black
▪ Protection rating: IP20
Mechanical Specification
▪ Length: 580 mm
▪ Width: 170 mm
▪ Height: 250 mm
Weight
▪ Net Weight: 9.0kgs
Accessories
▪ Power input cable included, length 1mtr
▪ DMX cable included, length 1mtr
▪ Safety cable not included (optional)
