Optical
▪ Light source：1x60W RGBW 4IN1
▪ Beam Angle： 3°-45°
▪ Lamp Luminous Efficiency(lm/w): 45
▪ CRI (Ra>): 85
▪ Light ouput (full Bright): 3° 32710Lux@2mtr; 8170Lux@4mtr
45° 580Lux@2mtr; 145Lux@4mtr
Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240V, 50-60 Hz
▪ Power consumption: 70W
▪ Power factor: 0.96
Color System
▪ Color Mixing: RGBW (4IN1)
Effects
▪ Strobe: 1-20 flashes/sec.
▪ Dimming : 0-100% linear
▪ Dimming mode: 32-bits dimming
▪ Built-in color changing macros
Control and Programming
▪ Control Mode: Sound Active/Auto-run/Master -slave/Standalone/DMX512
▪ DMX channels: 5/9CH
▪ DMX compliance: DMX512
▪ Display: LED
Connections
▪ Data in/out:3-pin （5-pin XLR optional)
▪ Power in/out: PowerCon
Cooling System
▪ Cooling: forced air convection, with 1pc slient fan (temperature-regulated, low noise, user-definable levels)
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 60° C
▪ Minimum ambient temperature (Ta min.): -40° C
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: Aluminum + Metal
▪ Color: black (white optional)
▪ Housing surface treatment: metal baking finished
▪ Protection rating: IP20
Mechanical Specification
▪ Length: 232 mm
▪ Width: 214 mm
▪ Height: 232 mm
Weight
▪ Weight:2.7kg
Accessories
▪ Power input cable included, length 1.4mtr
▪ DMX cable not included (optional)
Approvals
▪ CE
