LIGHT SOURCE
LEDs: 400W
Color temp: 2700K – 10000K
CRI: 95
Luminous flux: 18450lm
Drive mode: constant current
Drive current: 13A
OPTICS
Beam angle: 36°(19°/26°/50°optional)
Light ouput (full right):
36°: 1932 Lux@5mtr
Optic lens: Glass
DIMMER & STROBE
Electronic dimming: 0-100% linear
Refresh rate:1200-20000K Hz
Electronic strobe: 1-20 flashes/sec.
Built-in strobe macro: Speed adjustable
DIMMER & STROBE
Control protocol: DMX512
Control mode: RDM,DMX512,HSIC,MASTER/SLAVE,STAND ALONE
DMX channels: 11/5
DMX data In/Out: XLR 3Pin(XLR 5Pin Optional)
DISPLAY & MENU SETTING
Display: LCD
Setting and addressing: 4 buttons
Menu language: English
PAN-TILT
Tilt: ±150º (yoke)
BODY & HOUSING
Housing: Aluminium+Iron+ABS
Housing surface: Baking finish
Housing color: Black(White Optional)
POWER SUPPLY
Power supply: AC100V-240V; 50/60Hz
Power consumption: 600W
Power Supply Unit (PSU): 600W
Power In/Out: Powercon
Power linking: 4pcs@120V 4pcs@230V
COOLING
Cooling: Slient fan with tempeture control, Fan will will work till 57°C , fan speed can’t be adjusted
THERMAL MANAGEMENT
Overheat protection
It automatically turns off the light source when overheating
The temperature control system will prolong the life of the light source
SAFETY PROTECTION
Fuse：5A 230V
Electrical protection: Electronic anti-short-circuit protection
Rigging protection: with safety chain through holes at the yoke
RIGGING & MOUNTING
Mounting: Single Yoke
ENVIRONMENT AND PHYSICAL
IP rating: IP20
Environment temp: -20°C-45°C
Dimensions: 65.7X25.5X28.6cm
Net weight: 11.5kgs
ACCESSORIES
Power input cable: included ,length 1.2mtr
DMX cable: included, length 1.0mtr
Gel frame (filter frame): Optional
Gobo holder: Optional
Manual iris: N/A
Safety cable: Optional
