OPTICAL
▪ Light Source: RGBAL 300W R(20), G(14), B(14), A(18), L(24), 50,000 hours life expectancy
▪ CRI: 85
▪ Beam Angle: 36°(19°/26°/50°optional)
▪ Power consumption: 350W
DYNAMIC EFFECTS
▪ Dimmer: Electronic
▪ Shutter/Strobe: Electronic
▪ Strobe Rate: 0 to 20 Hz
▪ Color Temperature Presets: No
▪ Dim Modes: 4
▪ Built-in Automated Programs: Yes
CONSTRUCTION / PHYSICAL
▪ Dimensions: 720x330x315 mm
▪ Weight (single unit):10.5kgs
▪ Exterior Color: Black
▪ Housing Material: Aluminum die-cast
CONNECTIONS
▪ Power Connection: Powercon
▪ Cable Length (power): 1M
▪ Signal Connection: 3pin (5pin optional)
CONTROL
▪ Control Protocol: RDM / DMX
▪ DMX Channels: 5/10 CH
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): 5° C
CERTIFICATIONS / QUALIFICATIONS
▪ CE
▪ IP Rating: IP20 (indoor use)
WHAT’S INCLUDED
▪ Power cable 1 pc
▪ Signal cable 1 pc
▪ Gobo Holder
▪ Gel frame(i.e. filter frame)
OPTIONAL ACCESSORIES
▪ Manual iris
▪ Clamps
▪ Safety Chain
▪ Flightcase
