LIGHT SOURCE
▪ LEDs: COB 400W, 5IN1
▪ Color temp: 2700K-10000K
▪ Color rendering index(CRI): Ra>90
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
OPTICS
▪ Beam angle: 25°-50°
▪ Flicker free (refresh rate >100K Hz)
COLORS
▪ Color Mixing: RGBAL 5IN1
EFFECTS
▪ 16 bit smooth dimming
▪ Electronic dimmer: 0-100% linear
▪ Electronic strobe: 1-25 flashes/sec.
CONTROL AND PROGRAMMING
▪ DMX Channel: 5/9CH
BODY
▪ Housing: Die-Cast Aluminum
▪ Housing color: black (white optional)
▪ Housing surface treatment: baking finished
POWER SUPPLY
▪ Power consumption: Max. 420W
▪ Auto switching power supply unit
▪ Power supply: AC100V-240V, 50/60Hz (auto-ranging)
COOLING & THERMAL MANAGEMENT
▪ Cooling system: No noise fan (copper tube)
SAFETY DEVICES
▪ Power failure memory
▪ Electronic protection against short circuit
RIGGING
▪ With single mounting yoke
ENVIRONMENT AND PHYSICAL
▪ IP rating: IP20
▪ Environment temp: -20°C-45°C
▪ Dimensions(mm): L955 x W330 x H310 (with yoke)
▪ Net weight: 11.5 kgs
ACCESSORIES
• Gel frame(i.e. filter frame) included
• Gobo holder included
• DMX cable included
• Power input cable included, length 1.2mtr
• Power cable: 0.75mm2, PVC
• Safety cable not included (optional)
• Manual iris not included (optional)
