ELECTRICAL
▪ AC power: 100-240 V nominal, 50/60 Hz
▪ Typical total power consumption: 80 W
OPTICS
▪ Light source: 10X7W RGBWA+UV(6IN1)
▪ Beam Angle:25°(10°, 40° optional)
▪ Minimum LED lifetime: 50 000 hours (to >70% luminous output)
DYNAMIC EFFECTS
▪ Color mixing: RGBWA+UV(6IN1)
▪ Electronic dimming: 0 – 100%
CONTROL AND PROGRAMMING
▪ Control options: DMX512
▪ DMX channels: 11/7 CH
▪ DMX address setting: Control panel with LED display
▪ Flicker free operation
▪ Control mode:DMX/Mater-Slave/Auto Run/Manual
▪ Protocol: DMX512
CONSTRUCTION
▪ Housing: die-cast aluminium
▪ Color(s): Black
▪ Protection rating: IP65
INSTALLATION
▪ Mounting: Double bracket, surface for truss mount
▪ Orientation: Any
▪ Location: Outdoor use only
CONNECTIONS
▪ Power In/Out: waterproof, daisy chain
▪ DMX data in/thru: 3-pin XLR
THERMAL
▪ Cooling: natural convection (no fan, no noise)
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
PHYSICAL
▪ Length: 220 mm
▪ Width: 240 mm
▪ Height: 190 mm
▪ Weight: 3.6 kgs
ACCESSORIES
▪ Power In/Out cable attached to fixture: 1.5mm2, rubber, length 0.45mtr
▪ Power in conversion cable not included (optional)
▪ DMX in conversion cable not included (optional)
▪ Power extention cable not included (optional)
▪ DMX extention cable not included (optional)
▪ DMX In/Out cable attached to fixture: length 0.45mtr
▪ Hanging bracket included, 1pc
▪ Safety cable not included (optional)
APPROVALS
▪ CE
