LIGHT SOURCE
▪ LEDs: 1pc 200W White COB +24X5050 RGB 3IN1
▪ Color rendering index(CRI): Ra>80
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
OPTICS
▪ Beam angle: 12°
▪ Flicker free (refresh rate >1200 Hz)
▪ 16 bit smooth dimming
▪ Dimmer mode: 4 class dimmer delay
COLORS
▪ Color Mixing: RGB 3IN1
EFFECTS
▪ Electronic dimmer: 0-100% linear
▪ Electronic strobe: 1-20 flashes/sec.
CONTROL AND PROGRAMMING
▪ Control mode: Art-Net, DMX, Sound, Auto, Bulit-in Programs
▪ DMX Channels: 8CH
▪ Onboard programming functionality enables programming
without external DMX controller
▪ Link method: special quick lock, which can realize quick splicing of any shape
▪ Menu language: English
▪ DMX Data In/Out: XLR 3Pin (XLR 5Pin optional)
PAN-TILT
▪ Tilt: -180º～+180º
BODY
▪ Housing: Sturdy die-cast aluminium body conceived for long-time durability
▪ Housing: streching aluminium body
▪ Housing color: black
▪ Housing surface treatment: baking finished
POWER SUPPLY
▪ Power consumption: Max. 65 W
▪ Auto switching power supply unit, PFC>0.95
▪ Power supply: AC100V-240V, 50/60Hz (auto-ranging)
▪ Power In/Out: waterproof, daisy chain
COOLING & THERMAL MANAGEMENT
▪ Automatic break in power supply in case of overheating
▪ Entire casing as heat sink
▪ Cooling: waterproof fan
SAFETY DEVICES
▪ Power failure memory
▪ Electronic protection against short circuit
RIGGING & ASSEMBLING
▪ with double mounting yokes
ENVIRONMENT AND PHYSICAL
▪ IP rating: IP65
▪ Environment temp: -20°C-40°C
▪ Dimensions(mm): L163 x W230 x H95 (with yoke)
▪ Net weight: 2.5kg
ACCESSORIES
▪ Power In/Out cable attached to fixture: 2.50mm2, PVC
▪ Power In/Out cable attached to fixture: length 1.0mtr
▪ DMX In/Out cable attached to fixture: length 1.0mtr
▪ Power in conversion cable not included (optional)
▪ DMX in conversion cable not included (optional)
▪ Power extention cable not included (optional)
▪ DMX extention cable not included (optional)
▪ Safety cable not included (optional)
