LIGHT SOURCE
▪ LEDs: 1pc COB 80W, warm white
▪ LEDs brand: Jinxin
▪ Color temp: 2800-3000K
▪ Color rendering index(CRI): Ra>80
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
▪ Drive current(mA): 2500
OPTICS
▪ Beam angle: 60°
▪ Reflector material: aluminum
▪ Lens Type: Dichroic parabolic reflector in combination with HD fresnel lens
▪ Flicker free (refresh rate >1200 Hz)
▪ 16 bit smooth dimming
▪ Dimmer mode: 4 class dimmer delay
COLORS
▪ Single color, warm white
EFFECTS
▪ Electronic dimmer: 0-100% linear
▪ Electronic strobe: 1-20 flashes/sec.
CONTROL AND PROGRAMMING
▪ Control mode: DMX, autorun and Master/Slave
▪ DMX Channels: 2CH
▪ Onboard programming functionality enables programming
without external DMX controller
▪ Setting and addressing: 4-digit LED
▪ Menu language: English
▪ Display 30sec. auto sleep
▪ DMX Data In/Out: XLR 3Pin
PAN-TILT
▪ Tilt: -180º～+180º
BODY
▪ Housing: Sturdy die-cast aluminium body conceived for long-time durability
▪ Housing: streching aluminium body
▪ Housing color: black (silver, white optional)
▪ Housing surface treatment: baking finished
POWER SUPPLY
▪ Power consumption: Max. 92W
▪ Auto switching power supply unit, PFC>0.95
▪ Power supply: AC100V-240V, 50/60Hz (auto-ranging)
▪ Power In/Out: waterproof, daisy chain
▪ Power linking: up to 10units@120V and 20units@230V
COOLING & THERMAL MANAGEMENT
▪ Automatic break in power supply in case of overheating
▪ Entire casing as heat sink
▪ Cooling: natural convection
SAFETY DEVICES
▪ Power failure memory
▪ Electronic protection against short circuit
▪ with one eye bolt at the rear
RIGGING & ASSEMBLING
▪ with double mounting yokes
ENVIRONMENT AND PHYSICAL
▪ IP rating: IP65
▪ Dustproof at the front of head: tempered glass
▪ Environment temp: -20°C-40°C
▪ Dimensions(mm): L253 x W248 x H143 (without yoke)
▪ Dimensions(mm): L253 x W248 x H183 (with yoke)
▪ Net weight: 5.5kg
ACCESSORIES
▪ Power In/Out cable attached to fixture: 2.50mm2, PVC
▪ Power In/Out cable attached to fixture: length 1.0mtr
▪ DMX In/Out cable attached to fixture: length 1.0mtr
▪ Power in conversion cable not included (optional)
▪ DMX in conversion cable not included (optional)
▪ Power extention cable not included (optional)
▪ DMX extention cable not included (optional)
▪ Safety cable not included (optional)
