ELECTRICAL
▪ Power supply: Electronic auto-ranging
▪ Lens Angle: 25°(35°/45°optional)
▪ Power consumption: 400W
OPTICS
▪ Light Source: 24X15W, 5050, RGBW 4in1
▪ Color Temperature (range): 2000 K to 10000 K
▪ Drive Mode: Constant Current
COLOR SYSTEM
▪ Color Mixing: RGBW (4IN1)
EFFECTS
▪ Strobe: 0-20Hz
▪ Dimmer: Electronic
▪ Standalone Color Mixing: Yes
▪ Color Temperature Presets: Yes
▪ Dim Modes: 4
▪ Built-in Automated Programs: Yes
MOVEMENT
▪ Resolution: 8-16 Bit
▪ Position Feedback: yes
▪ Tilt (Degrees): 185°
CONSTRUCTION / PHYSICAL
▪ Dimensions: 48.2×17.8×24.3 cm
▪ Weight (single unit):10.0kgs
▪ Exterior Color: Black
▪ Housing Material: Aluminum die-cast
CONNECTIONS
▪ Power In/Out: Powercon
▪ Cable Length (power): 1M
▪ Signal Connection: 3pin / 5pin
CONTROL
▪ Control Mode: USITT DMX-512, RDM
▪ Control Modes: 7CH / 7CH (CTC) / 10CH / 11CH (CTC)
▪ Display: illuminated graphic LCD
▪ RDM: Bidirectional communication
COOLING SYSTEM
▪ Cooling: silent fan
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): 5° C
SAFETY DEVICES
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
CERTIFICATIONS / QUALIFICATIONS
▪ CE
▪ IP Rating: IP65 (outdoor use)
WHAT’S INCLUDED
▪ Power cable 1 pc
▪ Signal cable 1pc
▪ Hanging: Omega-Bracket
OPTIONAL ACCESSORIES
▪ Clamps
▪ Flightcase
